Gr. 5, Gr.9, Gr.12, Gr.23 Titanium Alloy Wire of ASTM B863
Gr. 5, Gr.9, Gr.12, Gr.23 Titanium Alloy Wire of ASTM B863Gr. 5, Gr.9, Gr.12, Gr.23 Titanium Alloy Wire of ASTM B863Gr. 5, Gr.9, Gr.12, Gr.23 Titanium Alloy Wire of ASTM B863Gr. 5, Gr.9, Gr.12, Gr.23 Titanium Alloy Wire of ASTM B863Gr. 5, Gr.9, Gr.12, Gr.23 Titanium Alloy Wire of ASTM B863Gr. 5, Gr.9, Gr.12, Gr.23 Titanium Alloy Wire of ASTM B863Gr. 5, Gr.9, Gr.12, Gr.23 Titanium Alloy Wire of ASTM B863
Gr. 5, Gr.9, Gr.12, Gr.23 Titanium Alloy Wire of ASTM B863Gr. 5, Gr.9, Gr.12, Gr.23 Titanium Alloy Wire of ASTM B863Gr. 5, Gr.9, Gr.12, Gr.23 Titanium Alloy Wire of ASTM B863Gr. 5, Gr.9, Gr.12, Gr.23 Titanium Alloy Wire of ASTM B863Gr. 5, Gr.9, Gr.12, Gr.23 Titanium Alloy Wire of ASTM B863Gr. 5, Gr.9, Gr.12, Gr.23 Titanium Alloy Wire of ASTM B863Gr. 5, Gr.9, Gr.12, Gr.23 Titanium Alloy Wire of ASTM B863
  • Description
  • Specification

    Titanium Alloy Wire

    Grades:
        Grade 5    Ti-6Al-4V

        Grade 6    Ti-5Al-2.5Sn

        Grade 7    Ti-0.2Pd

        Grade 9    Ti-3Al-2.5V

        Grade 12  Ti-0.3Mo-0.8Ni

        Grade 23   Ti-6Al-4V ELI


    Shape:
        Straight, in coil or spool

    Surface Treatment:
         Polished, Pickled

    Specifications:
         AWS A5.16, ASTM B863, AMS4951, AMS4954, ASTM F136

    Size:
        From 0.006" - 0.276"
        From 0.15 - 7mm


    Production Capability:

        72 Metric Tons/month

    Packing:
        Straight: sealed with plastic bag in plastic box + plywood case.
        In Coil: protected by foam paper+ plywood case.
        In spool: carton box + plywood case.
        As per customer’s requirement.


    Delivery Time:

         5-15 days

    Shipping:

        By International Express(TNT, FEDEX, DHL, UPS, etc.), By Air, By Sea


    Titanium Wire.pdf


    Titanium Alloy Wire


    Ti-Gr. 5: Recommended for high mechanical resistance applications up to 350° -400°C, it combines an ideal set of properties: high tensile strength, low density, toughness and ductility, weldability and machinability comparable to austeni1ic stainless steel.
    Suitable to solution and precipitation heat treatments.

    Ti-Gr. 5 Eli: Ti6Al4V with extra low interstitial elements content, with enhanced ductility, typically used in the non aged condition for maximum toughness. Widely used for cryogenic devices as well as medical applications.


    Chemical Composition:

    GradeNCHFeOAlVPdMoNiTi
    50.050.080.0150.400.205.5-6.753.5-4.5///Bal
    70.030.080.0150.300.25//0.12-0.25//Bal
    90.030.080.0150.250.152.5-3.52.0-3.0///Bal
    120.030.080.0150.250.25///0.2-0.40.6-0.9Bal
    230.030.080.01250.250.135.5-6.503.5-4.5///Bal


    Mechanical Property:

    GradeTensile   Strength(min)Yeild   Strength(min)Elongation(%)
    ksiMPaksiMPa
    Grade 513089512082810
    Grade 7503454027518
    Grade 9906207048315
    Grade 12704835034518
    Grade 2311579311075910
